Appendix
A.10 Measured Values
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
750
1053 Active Power Demand Reverse (Pdmd Rev
=)
Demand meter - - - - - CFC CD DD
1054 Reactive Power Demand Forward (Qdmd
Forw=)
Demand meter - - - - - CFC CD DD
1055 Reactive Power Demand Reverse (Qdmd
Rev =)
Demand meter - - - - - CFC CD DD
7731 PHI IL1L2 (local) (Φ IL1L2=) Measurement - - - - - CFC CD DD
7732 PHI IL2L3 (local) (Φ IL2L3=) Measurement - - - - - CFC CD DD
7733 PHI IL3L1 (local) (Φ IL3L1=) Measurement - - - - - CFC CD DD
7734 PHI UL1L2 (local) (Φ UL1L2=) Measurement - - - - - CFC CD DD
7735 PHI UL2L3 (local) (Φ UL2L3=) Measurement - - - - - CFC CD DD
7736 PHI UL3L1 (local) (Φ UL3L1=) Measurement - - - - - CFC CD DD
7737 PHI UIL1 (local) (Φ UIL1=) Measurement - - - - - CFC CD DD
7738 PHI UIL2 (local) (Φ UIL2=) Measurement - - - - - CFC CD DD
7739 PHI UIL3 (local) (Φ UIL3=) Measurement - - - - - CFC CD DD
7742 IDiffL1(% Operational nominal current)
(IDiffL1=)
IDiff/IRest 134 122 No 9 1 CFC CD DD
7743 IDiffL2(% Operational nominal current)
(IDiffL2=)
IDiff/IRest 134 122 No 9 2 CFC CD DD
7744 IDiffL3(% Operational nominal current)
(IDiffL3=)
IDiff/IRest 134 122 No 9 3 CFC CD DD
7745 IRestL1(% Operational nominal current)
(IRestL1=)
IDiff/IRest 134 122 No 9 4 CFC CD DD
7746 IRestL2(% Operational nominal current)
(IRestL2=)
IDiff/IRest 134 122 No 9 5 CFC CD DD
7747 IRestL3(% Operational nominal current)
(IRestL3=)
IDiff/IRest 134 122 No 9 6 CFC CD DD
7748 Diff3I0 (Differential current 3I0) (Diff3I0=) IDiff/IRest - - - - - CFC CD DD
7751 Prot.Interface 1:Transmission delay (PI1 TD) Statistics 134 122 No 9 7 CFC CD DD
7752 Prot.Interface 2:Transmission delay (PI2 TD) Statistics 134 122 No 9 9 CFC CD DD
7753 Prot.Interface 1: Availability per min.
(PI1A/m)
Statistics - - - - - CFC CD DD
7754 Prot.Interface 1: Availability per hour (PI1A/h) Statistics 134 122 No 9 8 CFC CD DD
134 121 No 9 3
7755 Prot.Interface 2: Availability per min.
(PI2A/m)
Statistics - - - - - CFC CD DD
7756 Prot.Interface 2: Availability per hour (PI2A/h) Statistics 134 122 No 9 10 CFC CD DD
134 121 No 9 6
7761 Relay ID of 1. relay (Relay ID) Measure relay1 - - - - - CFC CD DD
7762 IL1(% of Operational nominal current)
(IL1_opN=)
Measure relay1 - - - - - CFC CD DD
7763 Angle IL1_rem <-> IL1_loc (ΦI L1=) Measure relay1 - - - - - CFC CD DD
7764 IL2(% of Operational nominal current)
(IL2_opN=)
Measure relay1 - - - - - CFC CD DD
7765 Angle IL2_rem <-> IL2_loc (ΦI L2=) Measure relay1 - - - - - CFC CD DD
7766 IL3(% of Operational nominal current)
(IL3_opN=)
Measure relay1 - - - - - CFC CD DD
7767 Angle IL3_rem <-> IL3_loc (ΦI L3=) Measure relay1 - - - - - CFC CD DD
7769 UL1(% of Operational nominal voltage)
(UL1_opN=)
Measure relay1 - - - - - CFC CD DD
7770 Angle UL1_rem <-> UL1_loc (ΦU L1=) Measure relay1 - - - - - CFC CD DD
7771 UL2(% of Operational nominal voltage)
(UL2_opN=)
Measure relay1 - - - - - CFC CD DD
7772 Angle UL2_rem <-> UL2_loc (ΦU L2=) Measure relay1 - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
