Dimension drawings
12.7 Process connection label (pressure rated versions)
LR560 (PROFIBUS PA)
Operating Instructions, 06/2018, A5E34648471-AE
163
12.7
Process connection label (pressure rated versions)
For pressure-rated versions only, the process connection label lists the following information:
Item
Sample Text
Comments/Explanation
CONNECTION SERIES
ASME B16.5 / EN 1092-1/ JIS
B 2220
Flange Series: dimensional
pattern based on ASME
B16.5/EN 1092-1/JIS B 2 220
flange standards
NOM. PIPE SIZE (DN)
4 INCH / 100mm Nominal Pipe Size: based on
150#/PN16/10K flange pressure
classes
MAWP (PS)
3 BAR Maximum Allowable Working
Pressure at Design Tempera-
ture
DESIGN TEMP. (TS)
100 ºC Maximum Allowable Working
Temperature
MIN. PROCESS
3 BAR AT -40 ºC Minimum Wetted Process Con-
ditions
0F13589.5
Canadian Registration Number
(CRN)
TEST PRESSURE (PT)
5.2 BAR
Production Test Pressure
TEST DATE
10/01/04 Date of Pressure Test
(Year/Month/Day)
PROCESS SERIES
25785
Pressure Tag Family Series
WETTED NON-METALLIC
PEI
Sensor Lens Material
WETTED METALLICS
304L Process Connection Material(s)
WETTED SEALS
FKM / VQM
Seal Material(s)
