Operating
7.1 Remote operation
LR560 (PROFIBUS PA)
62 Operating Instructions, 06/2018, A5E34648471-AE
1. Go to LR560 (www.siemens.com/LR560) >
>
to download
the most up-to-date EDD.
2. Save files to your computer, and extract the zipped file to an easily accessed location.
3. Launch
SIMATIC PDM – Manage Device Catalog
, browse to the unzipped EDD file and
select it.
Firmware and Electronic device description (EDD) revisions
Clicking on
during an upload from device to SIMATIC PDM will result in some
parameters being updated.
Application Guides for setting up HART and Profibus PA devices with SIMATIC PDM can
be downloaded from our website:
LR560 (
www.siemens.com/LR560).
1. Check that you have the most recent EDD, and if necessary update it. See Updating the
Electronic Device Description (EDD) (Page 61).
2. Launch SIMATIC Manager and create a new project for the device.
3. Open the menu
and click on
to perform a reset to Factory
Defaults.
4. After the reset is complete upload parameters to the PC/PG.
5. Configure the device via the Quick Start wizard.
