Siemens Sonoline G20 User Manual

Siemens US06-101.812.01.02.02 SONOLINE G20
10.04 sd
SONOLINE G20 System Delivery Procedure 15
Page 15 of 26
Medical Solutions USA, Inc.
Verifications 0
Verify the Monitor Configuration 0
1. Set the brightness and contrast controls of the monitor to the center tactile (default posi-
tion), and then adjust the monitor for viewing as follows:
- Turn the Contrast control clockwise to increase the display contrast, and counter-
clockwise to decrease the contrast.
- Turn the Brightness control clockwise for a brighter image with a lighter back-
ground, and counterclockwise to darken.
Fig. 12: Brightness and Contrast Controls
2. Verify the date and time shown in the upper right corner of the screen is accurate.
Reset the time or date if either are inaccurate.
-Press F6 to display the Preset Main menu.
-Select Day / Time from the System Configuration submenu and press Set.
- Double-click the inaccurate field and type the correct time or date.
Press Tab to advance to the next field.
Fig. 13: Time and Date Fields
-Press Set.
-Select Save to save the new settings and exit the Preset Main menu.
