20 SONOLINE G20 System Delivery Procedure
SONOLINE G20 US06-101.812.01.02.02 Siemens
10.04 sd
Page 20 of 26
Medical Solutions USA, Inc.
3. Confirm that the printer DIP SW is configured as follows:
- Switch 1 set to ON (up)
- Switches 2 through 6 set to OFF (down)
Fig. 20: Printer DIP SW Settings
4. Power on the G20 system and then the printer.
5. Press F6 to display the Preset Main menu.
6. Select Customize Keys from the Preset Main menu and press the Set key.
7. Select B/W Print for the Print Store key.
Fig. 21: Customize Keys Submenu
8. Click Save and press Set.
9. Press Print/Store.
Confirm that the 2D image displayed on the monitor prints correctly from the printer.
