Installation
25
Building Technologies A6V10257473_b_en_--.doc
Fire Safety & Security Products 01.2010
XC1003-A, mounting adaptation
The 19” rack is symmetrical. This allows, with some mounting/unmounting
operations, to adapt it to various configurations (2 racks minimum are necessary).
A
B
B
A
B
Remove parts 5 & 6
from rack B
Reassemble parts 1, 2, 3 & 4 from
rack A in rack B
2 31 4
6
6
Remove parts 1, 2, 3 & 4
from rack A
A
Reassemble parts 5 & 6 from
rack B in rack A
1234
ON
1 2
ON
1 2
5
ON
1 2
ON
1 2
ON
1 2
5
Fig. 10 XC1003-A, mounting adaptation
