SSA3000X User Manual 5
Table 1-2 Function keys description
Set the parameters of freqency, and Peak→CF, CF→Step
Set the parameters of span, and X-scale(Log-Linear) setup
Set the parameters of amplitude, including Ref Level, Attenuator, Preamp, etc ;
and Correction setup
Scan the full span rapidly and move the biggest signal to center freq, and
automatically sets the optimal parameters according to the signal
Set the parameters of RBW and VBW, Average Type (Log power, Power,
Voltage), and Filter Type(-3 dB Gauss\ -6 dB EMI)
Select Trace, Trace setup and Trace math
Set the parameters of sweep ,and EMI QPD Dwell Time
Select the Detector type for each trace independently
Select triggers in Free Trigger, Video Trigger and External Trigger
Set the parameters of tracking generator. Including TG Level, TG Level offset,
Normalization setup. The backlight LED is on when TG source is on.
Set the demodulation parameters of the AM and FM for audio listening
Set the Markers and Marker Table
Set other system parameters on the basis of the current marker value.
Special functions of the marker such as noise marker, N dB bandwidth
measurement and frequency counter.
Search for the peak signal
In spectrum analyzer mode, selects the measurement function
In non spectrum analyzer mode, select corresponding settings.
Set the measurement parameters.
Set the system parameters
Select the working mode bwtween spectrum analyzer and other modes.
Set the display parameters.
Use the file system and files
Sets the system to certain status
Set the parameters of some functions between auto and manual.
Turn on the built-in help
To Next Page
