SSA3000X User Manual 33
1. Auto
When the sweep mode is autod, the analyzer selects the sweep mode automatically between
Sweep and FFT Mode in the shortest time.
2. Sweep
Work in point-by-point scanning. The Sweep mode is only available when RBW is in 30 Hz – 1
MHz.
3. FFT
Work in FFT scanning. The FFT mode is only available when RBW is in 1 Hz - 30 kHz.
When TG is on, the sweep mode is forced to Sweep.
2.2.4.5 QPD Dwell Time
Dwell time is the measurement time at a single frequency. QPD detector gets its weighted
envelope response during dwell time. The longer dwell time is, the more sufficiently QPD detector
responses to a single frequency, the more accuracy the QPD detector envelope is.
Table 2-18 QPD Dwell Times
Parameter
Explanation
Default
50 ms
Range
0 s ~ 10 s
Unit
ks, s, ms, us
Knob Step
N/A
Direction Key Step
N/A
2.2.5 Trigger
The trigger type can be Free Run, Video or External.
1. Free Run
The trigger conditions are satisfied at any time and the analyzer generates trigger signals
continuously.
2. Video Trigger
A trigger signal will be generated when the system detects a video signal of which the voltage
exceeds the specified video trigger level.
Set the trigger level in video trigger. At this point, the trigger level line (Trig Line) and value are
displayed on the screen.
