SIGLENT
SSA3000X User Manual 68
3. Switch on the analyzer
4. Press button on the front panel System →Interface→LAN to enter the LAN Config
function menu.
5. Select the IP Config between Static and DHCP
DHCP: the DHCP server in the current network will assign the network parameters
automaticlly (IP address, subnet mask, gate way) for the analzyer.
Static: you can set the IP address, subnet mask, gate way manually. Press Apply.
The analyzer will be detected automatically or manually as a new LAN point.
3.1.3 Connecting the Analyzer via the USB Host port
Refer to the following steps to finish the connection via USB:
1. Install NI-VISA on your PC for GPIB driver.
2. Connect the analyzer USB Host port to a PC’s GPIB card port, with SIGLENT
USB-GPIB adaptor.
3. Switch on the analyzer
4. Press button on the front panel System→Interface→GPIB to enter the GPIB
number.
The analyzer will be detected automatically as a new GPIB point.
