SSA3000X User Manual 60
Control the display grid brightness.
Table 2-40 Grid brightness
Parameter
Explanation
Default
30%
Range
0 ~ 100%
Unit
None
Knob Step
1%
Direction Key Step
1%
3. Screen Text
Open or close the current parameter and its value in the wave area.
4. Screenshot
Select the screenshot type to normal and color inverse.
The color of trace is not inversed in inverse mode.
2.5.3 File
2.5.3.1 Browser
Browser type including “Dir” and “File”,
Dir: when selected, use the knob or direction keys to browser directory in system
File: when selected, use the knob or direction keys to switch among files or folders under the
current directory.
2.5.3.2 Open/Load
Open the current folder or load current file
2.5.3.3 View Type
User can define the file type be browsed, included “All Type”, “STA”, “TRC”, “COR”, “CSV”,
“LIM”, “PIC(JPG/BMP/PNG)”.
2.5.3.4 Save Type
User can define the file type be saved, included “STA”, “TRC”, “COR”, “CSV”, “LIM”, “JPG,”
“BMP”, “PNG”.
