SIGLENT
SSA3000X User Manual 30
Table 2-15 Const
2.2.2.7 Output Z
The result Z will show on screen in trace A, B, C as you choose.
2.2.2.8 Calculation Type
Spectrum Analyzer provides the calculation types as shown below:
X-Y+Ref→Z
Y-X+Ref→Z
X+Y-Ref→Z
X+const→Z
X-const→Z
2.2.3 Detect
The analyzer displays the sweep signal on the screen in the form of trace. For each trace point, the
analyzer always captures all the data within a specific time interval and processes (Peak, Average,
etc.) the capture data using the detector currently selected, then display the processed data (one
point) on the screen.
Select an appropriate detector type according to the actual application in order to ensure the
accuracy of the measurement.
The available types are Pos Peak, Neg Peak, Sample, Normal, Average and Quasi Peak.
The default is Pos peak.
1. Positive Peak
For each trace point, Positive Peak detector displays the maximum value of data sampled within
the corresponding time interval.
2. Negative Peak
For each trace point, Negative Peak detector displays the minimum value of data sampled within
the corresponding time interval.
3. Sample
For each trace point, Sample detector displays the transient level corresponding to the central time
point of the corresponding time interval. This detector type is applicable to noise or noise-like
signal.
