SIGMATEK MDD 121-1 User Manual

MDD 121-1
10.03.2021 Page 19
2.9 Technical Data Axis Module 400 V/480 V
DIM
MDD 121-1
Article number
09-404-121-1
Rated Data
Nominal allowed mains voltage
V
AC
230/ 400 / 480
Max. holding brake current per axis
A
DC
1
Holding brake voltage drop from
+24 V-BR to output
V
DC
Max. 1 (at 1A holding brake current)
Max. holding brake switching energy
mJ
34
Max. continuous sum current of all axes
(heat sink) at 230 V
A
rms
6
Rated output current axis 1 (rms +/- 3 %)
at 230 V
A
rms
3, max 5*
Rated output current axis 2 (rms +/- 3 %)
at 230 V
A
rms
3
Max. continuous sum current of all axes
(heat sink) at 400 V/480 V
A
rms
4
Rated output current axis 1 (rms +/- 3 %)
at 400 V/480 V
A
rms
2, max 3*
Rated output current axis 2 (rms +/- 3 %)
at 400 V/480 V
A
rms
2
Max. peak sum current of all axes at
230 V for max 5 sec.
A
rms
18
Peak output current axis 1 for max 5 sec.
(rms +/- 3 %) at 230 V
A
rms
9, max 15**
Peak output current axis 2 for max 5 sec.
(rms +/- 3 %) at 230 V
A
rms
9
Max. peak sum current of all axes at
400 V/480 V for max 5 sec.
A
rms
12
Peak output current axis 1 for max 5 sec.
(rms +/- 3 %) at 400 V/480 V
A
rms
6, max 9**
Peak output current axis 2 for max 5 sec.
(rms +/- 3 %) at 400 V/480 V
A
rms
6
Power stage losses (sum average
currents of the 3 axis and multiply with
factor), without regen losses
W /
A
rms
10
Output frequency of the power stage
kHz
8
Regulator frequency
kHz
16
DC-Link capacitance
µF
60
Plug types
Feedback (X12, X22))
-
Sub-D 25-pole (female)
Motor (X11, X21)
-
Phoenix GMSTB 2,5HCV/ 6-ST-7,62
