MDD 121-1
10.03.2021 Page 49
5.2 Feedback (X12, X22)
The servo drive has feedback inputs for several different feedback devices.
• Resolver Feedback with thermal contact in the motor winding
• EnDat
®
encoder (single and multiturn)
• Hiperface® encoder (single and multiturn)
• Sin/Cos & TTL encoder
• Sanyo Denki absolute encoder
• Panasonic encoder
• BiSS C encoder
For EnDat, Hiperface, Sin/Cos, TTL and Sanyo Denki encoder systems, a maximum
number of 8192 feedback signals per mechanical rotation is supported (M-RPULSE).
