SIGMATEK MDD 121-1 User Manual

MDD 121-1
Page 32 10.03.2021
3.3.6 External Fusing
The AC-mains and 24 V – fuses are calculated depending on customer needs.
Signal
Fuses, time delay
AC mains input (L1-L3)
Suitable for use on a circuit
capable of delivering not
more than 5000 rms
symmetrical amperes, 528
Volts maximum when
protected by RK5 Class
Fuses rated 10 A/600 V with
MDP101-1 or
Suitable for use on a circuit
capable of delivering not
more than 5000 rms
symmetrical amperes, 253
Volts maximum when
protected by RK5 Class
Fuses rated 15 A/300 V with
MDP102-1.
Size fuses to the average power, needed by the servo drives,
connected to the circuit. Maximum rating is 12 A time delay
corresponding to cable diameter of 2.5 mm² (14 AWG) (FRS-25)
24 VDC input (24V, 24V-BR
to BGnd)
Limited to 12 A time delay at 2.5 mm² / 14 AWG
