MDP 101-1
Page 20 05.06.2020
Peak power of the internal regen resistor
(max. 1sec)
kW
27
Safety Input
Input voltage between ENABLE_H (+) and
ENABLE_L (-)
V
Typically 24, max 30 V
Signal level between ENABLE_H (+) and
ENABLE_L (-)
V
Low ≤ +5, High ≥ +15
Input current
mA
Typically 10 at 24 V
Switching delay times of the inputs
s
Switch-on about 0.02
Switch-off minimum 0.5, maximum 1 s
Relay output (S1, S2)
-
NO
Switching capacity
-
Max. 30 V
DC
, 42 V
AC
, 100 µA to 0.5A
Digital Input
Input voltage Dig_IN1 to Dig_IN8
V
Typically 24, max 30 V
Signal level
V
Low ≤ +5, High ≥ +15
Input current
mA
Typically 10 at 24 V
Switching delay times of the inputs
ms
Typically 0.1
Internal fusing
Auxiliary supply 24 V (+24 V to BGND)
-
Electronic fuse
Holding brake supply 24 V-BR (+24 V-BR to
BGND)
-
Electronic fuse
Regent resistor
-
Electronic protection
Resolver specification
Exciter frequency f
err
kHz
8
Exciter voltage U
Ref
U
eff
2,8
Number of poles m
-
2, 4, 6, .., 32
Resolver voltage U
sin/cos, max
U
eff
1,9
Plug types
Safety Inputs (X1)
-
Phoenix FK-MCP1,5/ 5-ST-3,5
Power Supply (X2)
-
Phoenix GMSTB 2,5HCV/ 9-ST-7,62
VARAN Bus (X3, X4)
(maximum length: 100 m)
-
RJ 45
Digital Inputs (X6)
-
Phoenix FK-MCP1,5/ 12-ST-3,5
Mechanics
Height
mm
155
Width
mm
60
Depth with module carrier (without/with
plugs)
mm
152/195
Weight
kg
1.2
