3.3.6 External Fusing
The AC-mains and 24 V – fuses are calculated depending on customer needs.
Signal
Fuses, time delay
AC mains input (L1-L3)
Size fuses to the average power, needed by the servo drives,
connected to the circuit.
Suitable for use on a circuit capable of delivering not more than
5000 rms symmetrical amperes, 528 Volts maximum when
protected by RK5 Class Fuses rated 10 A / 600 V.
24 VDC input (24 V, 24 V-
BR to BGnd)
Limited to 12 A time delay at 2.5 mm² / 14 AWG
