SIGMATEK MDP 101-1 User Manual

MDP 101-1
05.06.2020 Page 19
2.8 Technical Data Power Supply Module 400 V/480 V
DIM
MDP101-1
Article number
09-403-101-1
Hardware version
3.x
Rated Data
Rated mains voltage (symmetrically to
ground) maximum 5000 rms symmetrical
amps (L1, L2, L3)
V
AC
3 x 230 V
-10%
- 480 V
10%
, 45 – 65 Hz
Maximum peak current at switch on of the
mains contactor (limited by the inrush
circuit)
A
3
Rated installed power for S1 operation
kVA
3
Rated installed power for S1 operation for
input voltage < 400 V
VA
3 kVA – 7.5 W * (400 – input voltage/V)
Rated DC-link voltage
V
DC
290 - 680
Over voltage protection threshold of DC-link
voltage
V
DC
450, 800, 900
Auxiliary supply voltage +24 V
V
DC
22 - 30
Maximum leakage current
mA
30
Power of additional supply voltage +24 V
W
Max. 50
Holding brake supply voltage +24 V-BR
V
DC
23 - 26
(depending on type of selected holding brake)
Regen Circuit
DC-Link capacitance
µF
135
G-VMAINS = 230 (rated mains voltage = 230 V)
Switch-on threshold
V
DC
420
Switch-off level
V
DC
400
Over voltage protection
V
DC
450
Peak power of the internal regen resistor
(max. 1sec)
kW
5.3
G-VMAINS = 400 (rated mains voltage = 400 V)
Switch-on threshold
V
DC
730
Switch-off level
V
DC
690
Over voltage protection
V
DC
800
Peak power of the internal regen resistor
(max. 1sec)
kW
21
G-VMAINS = 480 (rated mains voltage = 480 V)
Switch-on threshold
V
DC
850
Switch-off level
V
DC
810
Over voltage protection
V
DC
900
