Signode MCD-310 - Parts List, Removal & Replacement

16
PARTS LIST
KEY QTY PART # DESCRIPTION
1 1 016120 Roll pin, 1/4 x 2-1/4
2 2 008597 O-ring, SAE 214
3 1 014620 Idler shaft
4 2 008596 O-ring, SAE 111
5 1 014739 Thrust bearing
6 1 014621 Idler gear
6A 3 014685 Roller clutch
7 1 014622 Idler pinion
8 1 014704 Sleeve bearing
9 2 014714 Belleville washer
10 1 014601 Vibrator gear
11 1 053043 Cam shaft cover
12 1 053054 Oil seal, C/R #10153
13 1 091863 O-ring, SAE 227
14 25 004238 Lockwasher, #10
15 4 004618 SHCS, #10-24 x 5/8
16 1 014679 Bearing, N/D Z99R16
17 14 002187 Lockwasher, 1/4
18 13 009041 SHCS, 1/4-20 x 3/4
19 1 053453 Kick tab
20 1 053454 Vibrator cam
21 2 014678 Truarc, #N5000-268
22 2 014681 Bearing
23 2 014623 Vibrator clutch
24 2 014677 Truarc, #5100-156
25 1 014720 Key
26 1 008378 Key
27 2 014676 Truarc, #5133-98
28 1 053040 Cam shaft
29 1 014609 Inner race assembly, for
MCD-310 only
1 042776 Inner race assembly, for
MCD-710 only
1 009884 Inner race assembly, for
MCD-510 only.
(Tenax strap only.)
Requires Std Vibrator
29A 1 014705 Sleeve bearing
31 2 014682 Bearing
32 3 014813 Spring
33 1 014608 Cam shaft cover
33A A/R 006697 Shims
34 2 014810 Roll pin, 1/4 x 1 1/4
35 2 043855 Roll pin, 5/32 x 1 1/4
36 28 009041 SHCS, 1/4-20 x 3/4
37 4 007146 SHCS, 1/4-20 x 1 1/4
38 1 014724 Sheave assembly
39 1 280720 Back clutch cover
39A 4 280721 Back cover shim
40 8 009050 SHFS, #10-24 x 5/8
41 1 053052 O-ring, SAE 135
42 1 053055 Oil seal
43 2 053059 Bearing
44 2 053042 Seal pinion stop
45 2 014807 Pinion stop spring
KEY
QTY PART # DESCRIPTION
46 1 014642 Right clutch pinion
47 1 014624 Tensioner Clutch
48 1 014672 Left clutch pinion
49 1 071636 Key
50 1 053039 Clutch shaft
51 1 053045 Front clutch cover
52 1 008546 O-ring, SAE 225
53 2 014728 Bearing, N/D Z99502
54 1 014811 Flexloc nut
55 1 014655 Spring spacer
56 8 014730 Belleville washer
57 2 014641 Clutch disc
58 1 014658 Slip clutch pinion
59 1 014657 Chain sprocket
60 1 015310 Feed shaft
61 2 008584 O-ring, SAE 113
62 1 053057 Oil seal, C/R #12384
63 1 014727 Bearing, N/D Z99604
64 1 053053 O-ring, SAE 139
65 1 053048 Feedwheel cover
66 1 053046 Tension shaft plug
67 1 014660 Tension shaft plug
68 1 014659 Tension gear
68A 2 014729 Roller clutch
69 1 014808 Chain
70 1 014666 Sprocket assembly
71 1 014663 Tension shaft
72 1 053041 Sprocket spacer
73 1 053056 Oil seal
74 1 053060 Bearing, N/D Z499604
75 1 007027 O-ring, SAE 141
76 1 053047 Tension shaft cover
77 2 072108 Flexloc nut
78 2 014722 Bearing
79 1 014639 Fork pin
80 1 014638 Knuckle pin
81 1 014633 Knuckle
82 2 053063 E-ring, X5133-31
83 1 014637 Fork
84 1 014643 Fork pivot pin
85 2 014652 Vibrator shaft keeper
86 3 008922 Pipe plug
87 1 053450 Gear housing
88 1 014634 Pusher
89 1 009719 Spring (Std. Tension)
1 014881 Spring (Low Tension)
90 1 014640 Tension regulator
91 4 014726 Tension stop ring
92 1 014721 Quad ring SAE 222
96 1 008361 Hand wheel
97 2 008853 FHSCS, 5/16-18 x 5/8
179 6 009397 SHCS, #10-24 x 1/2
