38
PARTS LIST ASSEMBLIES, CHUTE
The following illustrations are a representation of all MCD chute configurations. Actual part sizes and
lengths will vary. Each major component of the chute assembly has a unique key number. The following
pages of this manual are the parts list for each assembly configuration as described on page 32 of this
manual. Part numbers are then referenced by key on the appropriate parts list.
KEY
PART # DESCRIPTION
1 002844 HHCS, 3/8-16 x 1-1/4
2 009069 Hex nut, 3/8-16
3 006243 Lockwasher, 3/8
4 009092 HHCS, 3/8-16 x 1-1/2
5 006978 Set screw, 1/4-28 x 5/16
6 006293 HHCS, 3/16 x 1
7 004361 Set screw, 1/4-28 x 7/16
8 257487 Allen wrench
9 260419 Facegate, Short vibrator (18" & 24" Chute heights)
260418 Facegate, Std vibrator (30" 36" 48" 60" 72" Chute heights)
10 257483 Chute mounting bracket
11 257489 Chute cap
12 274482 Chute bracket
13 257469 Chute corner
14 257485 Bracket conveyor support
15 257488 Chute mounting bracket
16 257484 Chute mounting bracket
17 254952 Gate, left
18 254953 Gate, right
19 257478 Bracket, conveyor support
20 257476 Bracket, conveyor support
21 001601 Base extension
22 260312 Base extension
25 * Chute, right
26 * Chute, top
27 * Chute, left
28 * Chute, bottom
29 * Gate, right
30 * Gate, top
31 * Gate, left
32 * Gate, bottom
33 * Conveyor roller
34 265503 Rubber spring
35 * Conveyor roller
43 014571 SHCS, 1/4-20 x 1-1/4
44 015137 Locknut, 1/4-20
* Variable component part, review matrix information shown on the following pages.
For Parts & Service 1-877-862-6699
