Siko AP10 Installation Instructions

AP10
Commissioning English
AP10 · Date 10.01.2020 · Art. No. 86832 · Mod. status 6/20
35
Press key for changing actual value and / or the blinking digit when
entering a multi-digit value.
The key serves for switching to the next digit in case of multi-digit
numbers.
By pressing the key, the set value is acknowledged and saved non-
volatilely. If no key is pressed, the configuration mode will be exited after
~30s without saving the latest value displayed, i. e. the original value will
be maintained.
Configuration parameters CAN
Parameter Value range Default Meaning/Remark
ID 1 ... 127 125 bus address
NOTICE
Restart is required after chang-
ing these parameters!
KBAUD 125, 250, 500,
800, 1000kbd,
Auto
Auto CAN baud rate (e. g. 250kbit/s)
CODE 0 ... 999999
000100
011100
0 for test/diagnosis purposes
start calibration travel (see
chapter 5.1)
load factory settings
Configuration parameters RS485
Parameter Value range Default Meaning/Remark
ID 1 ... 127 31 bus address
NOTICE
Restart is required after chang-
ing these parameters!
KBAUD 19.2, 57.6,
115.2
57.6 SIKONETZ baud rate (e. g.
57.6kbit/s)
Protcl SN5, SEruic SN5 SIKONETZ protocol
bUS to 0 ... 20 0 Bus Timeout
Inhibt 0 ... 10 0 Response delay
CODE 0 ... 999999
011100
0 for test/diagnosis purposes
load factory settings
