Siko AP10 Installation Instructions

AP10
Technical data English
AP10 · Date 10.01.2020 · Art. No. 86832 · Mod. status 6/20
41
Electrical data Additional information
Current consumption ~30mA if operated with LEDs, plus
~3mA per LED
Power input ~0.72VA Max. power supply of the power
supply unit used: 100VA.
The power supply used corres-
ponds to SELV/Limited Energy
(IEC 61010-1) or SELV/LPS (IEC
60950-1) or Class 2 (UL 1310).
Battery service life ~5 years
Parameter memory 10
5
cycles also applies to calibration pro-
cedures
Display/display range 6 digits LCD 14-segment,
~8mm height
decimal point, two lines, special
character (LED behind is ligh-
ting red/white)
Special character arrow clockwise direction,
arrow anticlockwise direction,
'incremental measurement',
battery
Status display 2x 2-color LED (red/green) programmable position status
Keys keys for 'incremental mea-
surement', for programming
and reset
Interface RS485; CANopen; IO-Link no galvanic isolation
Type of connection 2x M8 connector (A coded) 4 poles, 1x socket, 1x pin
(RS485, CANopen)
1x M8 connector (A coded) 4 poles, 1x pin (IO-Link)
grounding via flat male tab
6.3mm or terminal lug
System data Additional information
Scanning magnetic
Resolution 880 increments/revolution displayed value/revolution
freely configurable
Measuring range ≤11914 revolution(s)
Approval UL UL 61010-1, File Nr. E503367
Ambient conditions Additional information
Ambient temperature 0 … 60°C
Storage temperature -20 … 80°C
Relative humidity condensation not permitted
