Cancelling Reservation Mode
Reservation mode will be cancelled for the following reasons;
• You did not activate the parking brake prior to turning off the ignition.
• You pressed the foot brake after the key was removed from the ignition.
• You released the parking brake after the key was removed from the ignition.
• You entered valet mode, opened the vehicle’s door, hood, trunk or set off the alarm.
L. Shutdown Diagnostics:
The unit has the ability to report the cause of the last shutdown of the remote start system.
Press Buttons + simultaneously.
4 Button Remote Transmitter: The parking light and chirps will report the reason of the system last shutdown by
ashing in the following grouped patterns,
LCD Remote Transceiver: The LCD display on the 2-way remote will report the reason of the last shutdown. And
the text and a fault tone play to conrm.
GROUP 1 (One Flash of Parking Light )
Chirps Shutdown Mode Solution
1
Hood Open
• Close the hood.
• Check 24-pin White/Black wire connection.
2
Optional Enable Switch OFF or Black/
White must have a ground
• Check 24-pin Black/White wire connection.
• Move the Enable Toggle Switch to “ON” position. (If installed.)
• Move the gear selector to “Park”/ “NEUTRAL” position
3
Foot Brake on
• Check 24-pin White/Violet wire connection
• Release Foot Brake.
4
System is in Valet Mode Exit the Valet mode
5
Hi Voltage
(Voltage Checking Type)
Set the “Feature 3-02 to “Low Level”
Low or No RPM
(Tachometer Checking Type)
• Check 24-pin White/ Red wire connection
• Set the “Feature 3-02 to “Hi Level”
• Re-learning the RPM
6
The engine has run successfully but is
still starting
(Tachometer Checking Type)
• Set the “Feature 3-02 to “Low Level”
GROUP 2 (Two Flash of Parking Light )
Chirps Shutdown Mode Solution
1
Over-Rev Shutdown
2
Running Time expired
3
Transmitter Shutdown
4
Wait-to-start input timed out (For Diesel Engine Only)
5
Alarm triggered
