E. CHIRP INDICATORS PARKING LIGHT
Chirp Function Parking light Function
1 Chirp Arm 1 Flash Arm
2 Chirps Disarm 2 Flashes Disarm
3 Chirps Defective Reminder 3 Flashes Disarm / Triggered Warning
4 Chirps Disarm / Triggered Warning 12 Flashes Car Locator
6 Chirps Car Locator Constant On Under Remote Start
TABLE OF ZONE / ALARM DIAGNOTICS
Situation Situation LED On Duty
Zone 1 (Door Triggered) 1 ashes, break, then repeat
Zone 2 (Trunk Triggered) 2 ashes, break, then repeat
Zone 3 (Hood Triggered) 3 ashes, break, then repeat
Zone 4 (Ignition Triggered) 4 ashes, break, then repeat
Zone 5 (Shock Triggered) 5 ashes, break, then repeat
Zone 6 (tilt Triggered) 6 ashes, break, then repeat
ALARM OPERATING CONDITION
LED On Duty Siren / Horn Parking Light LED Doors Starter Dome Light
Arming 1 or 3 Chirps 1 Flash
Slow
Flash
Locking Disable
Disarming 2 or 4 Chirps
2 or 3 Flash-
es
OFF Unlocking
Turns on for
30-Seconds
Trigger Alarming Flashes
Flashes
Pause
Disable Flashes
Hidden Alarm Flashes
Slow
Flash
Disable Flashes
30 Sec. Passive Arming
Fast
Flash
Panic Alarming Flashes Flashes
Car Locator 6 Chirps 12 Flashes Locking
F. ACTIVE ARMING – LOCK & ARM
1. Press the button on the transmitter.
2. The alarm arms, doors lock (if connected), and the siren chirps and parking lights ash once indicating that the
security system is now armed. The icon and beeps play to conrm. If Valet Mode* is ON, the doors lock and
the + icon and tone play on the LCD transceiver. Exit Valet Mode to arm the alarm normally.
DEFECTIVE SENSOR REMINDER: If the siren sounds 3 chirps and the defective / / icon
will display on the LCD screen, then then you have left a door, trunk, or hood lid ajar and the defective icon
will display onthe LCD screen.
