SIM868_Series_Hardware_Design_V1.06 62 2017-07-13
4 22 ±3 ±4
5 20 ±3 ±4
6 18 ±3 ±4
7 16 ±3 ±4
8 14 ±3 ±4
10 10 ±4 ±5
11 8 ±4 ±5
12 6 ±4 ±5
13 4 ±4 ±5
For the module’s output power, the following should be noted:
At GSM900 and GSM850 band, the module is a class 4 device, so the module’s output power should not exceed
33dBm, and at the maximum power level, the output power tolerance should not exceed +/-2dB under normal
condition and +/-2.5dB under extreme condition.
At DCS1800 and PCS1900 band, the module is a class 1 device, so the module’s output power should not exceed
30dBm, and at the maximum power level, the output power tolerance should not exceed +/-2dB under normal
condition and +/-2.5dB under extreme condition.
8.9.2. Module RF Receive Sensitivity
Table 44 shows the module’s conducted receiving sensitivity; it is tested under static condition.
Table 44: Conducted RF receive sensitivity
Frequency Receive sensitivity
Typical
Receive sensitivity(Max)
GSM850,EGSM900 < -109dBm < -107dBm
8.9.3. Module Operating Frequencies
The Table 45 shows the module’s operating frequency range; it follows the 3GPP TS 05.05 technical
specification requirement.
Table 45: Operating frequencies
Frequency Receive Transmit
GSM850
869 ～ 894MHz 824 ～ 849MHz
EGSM900
925 ～ 960MHz 880 ～ 915MHz
～
～
PCS1900
～
～
