SimCom SIM7000G - Hardware Interface Overview

Smart Machine Smart Decision
SIM7000 _Hardware Design _V1.00 2017-05-23
1.2 Hardware Interface Overview
The interfaces are described in detail in the next chapters include:
● Power Supply
● USB Interface
● UART Interface
● SIM Interface
● ADC
● LDO Power Output
● PCM Interface
● I2C Interface
● GPIOs
● Antenna Interface
