1.4 Functional Overview
Table 2: General features
Feature
Implementation
Power supply
Power supply voltage 3.0～4.3V
Power saving
Current in sleep mode: 1mA
Current in PSM mode: 9uA
Radio frequency bands
Please refer to the table 1
Transmitting power
LTE CAT-M1power class: 3 (0.25W)
Data Transmission
Throughput
LTE CAT-M1CAT M1: 300Kbps (DL)
LTE CAT-M1CAT M1: 375Kbps (UL)
Antenna
LTE CAT-M1main antenna.
GNSS antenna
GNSS
GNSS engine (GPS,GLONASS and BD)
Protocol: NMEA
SMS
MT, MO, CB, Text and PDU mode
SMS storage: SIM card or ME(default)
SIM interface
Support identity card: 1.8V/ 3V
SIM application toolkit
Support SAT class 3, GSM 11.14 Release 98
Support USAT
Audio feature
Support PCM interface
Only support PCM master mode and short frame sync, 16-bit linear data
formats
UART interface
A full modem serial port by default
Baud rate: 300bps to 4Mbps(default:115200bps)
Can be used as the AT commands or data stream channel
Support RTS/CTS hardware handshake
Multiplex ability according to GSM 07.10 Multiplexer Protocol
USB
USB 2.0 high speed interface
Firmware upgrade
Firmware upgrade over USB interface
Physical characteristics
Size:24 × 24 × 2.6mm
Weight:3g
Temperature range
Normal operation temperature: -30°C to + 80°C
Extended operation temperature: -40°C to + 85°C*
Storage temperature -45°C to + 90°C
*Note: Module is able to make and receive voice calls, data calls, SMS and make GPRS/LTE
CAT-M1traffic in -40℃ ~ +85℃. The performance will be reduced slightly from the 3GPP
