Smart Machine Smart Decision
SIM7000 _Hardware Design _V1.00 2017-05-23
GPIO
NETLIGHT
52
DO
LED control output as network
status indication.
If unused, keep them
open.
STATUS
66
DO
Operating status output.
High level: Power on and
firmware ready
Low level: Power off
GPIO0
50
IO
Default: GPIO
Optional: UART3_TXD
GPIO1
49
IO
Default: GPIO
Optional: UART3_RXD
GPIO2
67
IO
GPIO
GPIO3
68
IO
GPIO
GPIO4
48
IO
GPIO
RF interface
GNSS_ANT
53
AI
GNSS antenna soldering pad
RF_ANT
60
AIO
MAIN antenna soldering pad
Other interface
BOOT_CFG
6
DI,PD
Boot configuration input.
Module will be forced into
USB download mode by
connect this pin to VDD_EXT
during power up.
Reserve two test points
for BOOT_CFG and
VDD_EXT.
DO NOT PULL UP
BOOT_CFG
DURING NORMAL
POWER UP!
MDM_LOG_T
X
23
DO
Module log output for SW
debug. (only used for platform)
Reserve a test point for
this pin.
ADC
25
AI
Analog-digital converter input.
voltage range: 0.11.7V.
If unused, keep them
open.
NC
1920
21 22
2635
3640
41 42
43 44
47 51
No connection.
Keep it open
