Smart Machine Smart Decision
SIM7000 _Hardware Design _V1.00 2017-05-23
Figure 35: Tray drawing
Table 35: Tray size
Length
(±
3mm
Width
(±
3mm
Module number
242.0
161.0
20
Small carton drawing
Figure 36: Small carton drawing
Table 36: Small Carton size
Length
(±
10mm
Width
(±
10mm
Height
(±
10mm
Module number
270
180
120
20*20=400
Big carton drawing
Figure 37: Big carton drawing
