SIM800C_Hardware_Design_V1.02 43 2015-4-27
@ f>200kHzss 2.0 mV
Power off mode 130 150 uA
Sleep mode (AT+CFUN=1)：
( BS-PA-MFRMS=9 )
( BS-PA-MFRMS=5)
( BS-PA-MFRMS=2)
0.88
1
1.5
mA
mA
mA
Idle mode (AT+CFUN=1)：
GSM850
EGSM900
DCS1800
PCS1900
13.8
13.8
13.8
13.8
mA
mA
mA
mA
Voice call (PCL=5)：
GSM850
EGSM900
Voice call (PCL=0)：
DCS1800
PCS1900
209
211
126
413
mA
mA
mA
mA
Data mode GPRS (1Rx,4Tx)：
GSM850
EGSM900
DCS1800
PCS1900
394
416
271
285
mA
mA
mA
mA
Data mode GPRS (3Rx,2Tx)：
GSM850
EGSM900
DCS1800
PCS1900
323
330
212
227
mA
mA
mA
mA
I
VBAT
Average currnet
Data mode GPRS (4Rx,1Tx)：
GSM850
EGSM900
DCS1800
PCS1900
213
210
150
162
mA
mA
mA
mA
I
MAX
Peak current During Tx burst 2.0 A
Note: In above table the current consumption value is the typical one of the module tested in laboratory. In the
mass production stage, there may be differences among each individual.
6.9 Electro-Static Discharge
SIM800C is an ESD sensitive component, so attention should be paid to the procedure of handling and
packaging. The ESD test results are shown in the following table.
Table 35: The ESD characteristics (Temperature: 25℃, Humidity: 45 %)
Pin name Contact discharge Air discharge
VBAT ±5KV ±12KV
