Smart Machine Smart Decision
SIM800C_Hardware_Design_V1.02 45 2015-4-27
4 22 ±3 ±4
5 20 ±3 ±4
6 18 ±3 ±4
7 16 ±3 ±4
8 14 ±3 ±4
9 12 ±4 ±5
10 10 ±4 ±5
11 8 ±4 ±5
12 6 ±4 ±5
13 4 ±4 ±5
14 2 ±5 ±6
15 0 ±5 ±6
6.10.2 Module RF Receive Sensitivity
The following table shows the module’s conducted receiving sensitivity, it is tested under static condition.
Table 38: Conducted RF receive sensitivity
Frequency
Receive sensitivity（Typical）
Receive sensitivity(Max)
GSM850,EGSM900 < -109dBm < -107dBm
DCS1800,PCS1900 < -109dBm < -107dBm
6.10.3 Module Operating Frequencies
The following table shows the module’s operating frequency range; it is followed by the 3GPP TS 05.05
technical specification requirement.
Table 39: Operating frequencies
Frequency Receive Transmit
GSM850 869 ～ 894MHz 824 ～ 849MHz
EGSM900 925 ～ 960MHz 880 ～ 915MHz
DCS1800 1805 ～ 1880MHz 1710 ～ 1785MHz
PCS1900 1930 ～ 1990MHz 1850 ～ 1910MHz
