58
Edea 40
Pos.
Code Description
Advised
parts
001 6278972 Heat exchanger gas-water C
002 6326953 Sealing C
003 6326951 Rear insulation + springs
004 6248876 Smoke outlet gasket ø80 mm C
005 6277130 Probe NTC D.4X40 A
006 6291162 Upper protection shield
007 6278706 Smoke chamber
008 6248855 P.C. inlet/oulet smokes gasket C
009 5188364 Main exchanger door
010 6211794 Peephole kit + gasket C
011 6269034 Insulation
012 8076127 Burner + gasket kit C
013 6278813 Air-gas hose lower side
014 5200312 Air/gas mixer assembly
015 6226470 ORing 52,07 x 2,62 C
016 6322305 Round nozzle Ø 4,0
017 6322355 Hexagonal nozzle Ø 4,50
018 6226403 O-ring 2031 C
019 6267119 Nozzle locking bracket
020 6226465 O-ring Ø 183,83x2,62 C
021 6278812 Air-gas hose upper side
022 6281609 Ignit.-ionis.electrode +gasket B
023 6174816 Gasket for fan flange C
024 6261405 Fan A
025 6028703 Gasket for duct flange C
026 6083056 Duct flange 50
027 6273608 Water pressure transducer A
028 6226639 Spring clip
029 6226476 ORing diam.15x2 C
030 6017405 Flexible pipe M.F. 3/8" L=300
031 6226643 Pipe fixing spring
032 6281716 Hydrometer + spring B
033 2030226 Gasket Ø 10,2x14,8x2 C
034 6243840 Gas valve A
035 2030228 Gasket Ø 17x24x2 C
036 6277211 Water trap C
037 5171635 Cap + gasket for water trap kit C
038 1010215 Rubber pipe dia. 15x2,5 L=0,5 m
039 2051120 Clamp diam. 17,3
040 5183730 Rectang. expansion vessel L.10 C
041 6034155 Condensate drainage pipe
042 2051122 Clamp
043 2051123 Clamp diam.
044 6277479 Pipe connecting gas valve
045 2030255 Gasket Ø 12,5x18,5x3 C
046 6227561 Flow pipe
047 6226412 O-ring 3068 C
048 6226619 Spring for heat exchanger conne
049 6226601 Spring for heat exchanger conne
050 6227548 Return pipe from C.H. system
051 2030267 Piracriten gasket Ø 30x17x2 C
052 6146729 100¢C safety stat A
053 6231372 Temperature sensor A
054 6001182 Air intake superior pipe ø55
A
Spare parts for minimum fittings
A+B
Spare parts for basic safety fittings
A+B+C
Spare parts for extended safety fittings
Pos.
Code Description
Advised
parts
055 2051252 Hose clamp Ø 53-57
056 6001183 Air intake inferior pipe ø55
057 1010209 Silicon pipe Ø 8x1.5
058 6188883 Noise reduction pipe
059 6329900 Rubber button C
060 6329800 Interface panel
061 6290170 Knob Ø 20
062 6304480 casing left/right side panel
063 6304251 Casing front panel
064 6281730 Door for front panel
065 6299760 Frame for front panel
066 6329960 Rubber cap
067 6028665 Smoke exhaust diaphragm
068 6226757 Plug for noise reduction
070 6265866 C.H. flow manifold C
071 6265834 C.H. return manifold C
072 6319692 Kit 16 plate heat exchanger + o C
073 6226475 ORing diam.18,64x3,53 C
074 6222003 D.H.W. filter C
075 6131440 Flowmeter sensor B
076 6040225 Pressure relief valve 1/2" 3 ba C
077 6281519 Plunged sensor + gasket A
078 6226645 Spring clip
079 6120560 Pump nipple 3/4"
080 6226475 ORing diam.18,64x3,53 C
081 6330401 Modulating circulating pump B
082 6226644 Spring clip for rotating connec
083 6087332 Motor for diverting valve B
084 6226636 D.H.W. elektrovalve fix.spring
085 6226638 Divertor valve motor spring cli
086 6319644 Flowmeter group B
087 6319645 Three-way plates group B
088 6319647 Circulateur top cover
089 6013182 Automatic air vent C
091 6157660 Pressure relief valve drain pip
095 6304720 Control panel
096 6324982 Main P.C.B A
097 6329610 4 pole cable connector CN13 B
098 6329477 6 pole cable connector CN12 B
099 6329611 4 pole cable connector CN14 B
100 6325811 14 pole cable connector CN15 B
101 6329457 6 pole cable connector CN2 B
102 6325671 9 pole cable connector CN1 B
105 2030227 Gasket Ø 12x18x2 C
106 6177505 Ball cock 3/4" x 22 C
107 6177506 Ball cock 1/2" x 15 C
108 6142330 Quarter bend 1/2" x 15 C
109 2030249 Gasket Ø 24x17x3 C
110 6177530 Gas cock 3/4" F x 15
111 6281444 Water rate adjuster 18 l/min C
700 5202587 Complete control panel A
701 5185156 L.P.G. conversion kit
702 5185163 Conversion kit for natural gas
703 5184817 Fitting cocks kit C
