Simplex 4098-9614 Applications Manual

2-5
This section contains general notes, specifications, and mounting information for the heat
detectors shown in Table 2-2.
WARNING: Heat detectors are NOT life-safety devices; USE HEAT DETECTORS
FOR PROPERTY PROTECTION ONLY! For life-safety requirements,
use smoke detectors.
Notes:
 For all heat detectors, provide electronic supervision with battery back-up at the fire alarm
control panel.
 Where the possibility of positive airflow from the electrical conduit/junction box exists, seal
the conduit openings with 3M Weatherban #606 (or equivalent), a non-flammable sealing
compound.
 Refer to NFPA 72 for application, test, and maintenance requirements.
Fixed Temperature Heat Detectors:
Electronic fixed temperature heat detectors use a fast response, thermistor based design to provide
temperature sensing that quickly, accurately, and consistently identifies when fixed temperatures are
exceeded. For this reason, the fixed temperature detectors are recommended for most applications.
With a UL spacing distance of 60 X 60 feet, the fixed temperature electronic heat detectors replace
both mechanical fixed as well as mechanical ROR heat detectors.
ROR Temperature Heat Detectors:
Electronic Rate-of-Rise (ROR) heat detectors detect fixed temperature alarm thresholds the same as
the fixed temperature heat detectors, plus detect a ROR alarm with a patented ROR detection design
that can quickly respond to sudden temperature variations. Due to the nature of the fast response to
temperature changes, care must be taken for proper installation of ROR heat detectors. ROR heat
detectors should be installed in stable environmentally controlled areas. These detectors must not be
installed where hot or cold air can be blown on them (near ductwork, industrial equipment, air vents
etc.). ROR detectors should not be installed where more then 6 F per minute temperature changes
can normally occur.
Features:
 Rate-of-Rise and Fixed Temperature (see Table 2-2)
 Alarm LED
 Compatible with 2-Wire Initiating Device Circuits
 Current-Limited Alarm State
Electrical Specifications:
 Typical Standby Current - 80 Microamps
 Typical Alarm Current - 40 Milliamps
 Maximum Current - 80 Milliamps while in alarm state
 Operating Range - 15-32 VDC
 Maximum Ripple Voltage Allowed - 30%
Continued on next page
4098 Heat Detectors
Introduction
Heat Detector Types
Specifications
