5-10
Table 5-5. Sensor’s Analog Value
Trouble Indications,
Continued
The panel will automatically indicate
when a se
nsor is out of its se
nsitivity calibration. If
the sensor has an analog v
alue below what is lis
ted in the table, the sensor is within its
sensitivity setting.
Sensor’s Analog Value
Type
Almost Dirty
Dirty
Excessively Dirty
Photo 115
120
135
Ion 135
140
155
To view a Sensor’s analog value, refe
r to your panels operating instructions
firealarmresources.com
57
59
Table of Contents
default chapter
3
Copyrights and Trademarks
3
Trademarks
3
Cautions and Warnings
4
Table of Contents
5
Chapter 1 Overview
9
Introduction
9
In this Chapter
9
Special Considerations
10
Overview
10
Special Considerations for Smoke Detectors and Sensors
10
Smoke Detector/Sensor Applications
10
Where to Place Detectors and Sensors
11
Proper Locations for Detectors and Sensors
11
Where Not to Place Detectors and Sensors
14
Improper Locations for Detectors and Sensors
14
Principles of Operation
16
Introduction
17
Chapter 2 4098 Smoke Detectors, Heat Detectors and Bases
17
In this Chapter
17
4098 Smoke Detectors
18
Introduction
18
Smoke Detector Limitations
18
Specifications
19
Mounting Requirements
20
4098 Heat Detectors
21
Introduction
21
Heat Detector Types
21
Specifications
21
4098 Bases
24
Introduction
24
Mounting
25
Wiring
26
Chapter 3 Truealarm Sensors, Sensor Bases, and Quickconnect Smoke Sensors
31
In this Chapter
31
4098 Truealarm Sensors
32
Specifications
32
Special Applications
32
Mounting
32
4098 Truealarm Sensor Bases
33
Introduction
33
Specifications
33
Setting the Base's Address
33
Address Setting for the 2120 CDT System
35
Multi-Sensor Bases 4098-9795 and 4098-9796
37
Wiring
37
4098 Truealarm Quickconnect Smoke Sensors
42
Overview
42
Specifications
42
Setting the Sensor's Address
43
Wiring
44
Chapter 4 Accessories
45
In this Chapter
45
Relay Module Accessories
46
2098-9737 Relay Module Wiring
46
4098-9822 Relay Module Wiring
47
Relay Module Installation
48
Remote LED Module
48
Chapter 5 Compatibility and Testing
49
Introduction
49
In this Chapter
49
Compatibility
50
Compatibility for 4098 Detectors and Detector Bases
50
Maintenance and Testing
52
Maintenance
52
Preferred Method of Testing Smoke Detectors/Sensors
52
Test Equipment Available
52
Alternate Method for Testing Sensors
53
Magnetic Test for Photoelectric Detectors
53
Magnetic Test for Ionization Detectors
55
Ion Detector Sensitivity Test
55
Cleaning
56
Introduction
56
Photoelectric Smoke Detector/Sensor Cleaning
56
Trouble Indications
57
Trouble Indications for Truealarm Sensors
57
Trouble Indications, Continued
58
