3-12
This section contains general notes, specifications, and mounting information for the TrueAlarm
QuickConnect Smoke Sensor shown in Table 3-4.
WARNING: Ensure that the location of each smoke sensor has been planned
per local and national fire codes (see NFPA 72).
1. Smoke sensor sensitivities are set and continuously monitored by the control panel.
This functionality complies with NFPA 72. When functional testing of these sensors is
required per NFPA 72, use the test methods described in the “Compatibility and Testing”
chapter of this publication. The sensitivity range (settings) of the 4098-9757 is 1.5%/ft to
3.7%/ft smoke obscuration.
2. Refer to NFPA 72 for application, test, and maintenance requirements.
Table 3-4. TrueAlarm QuickConnect Smoke Sensor Specifications
Sensor PID 4098-9757
Type of Sensor
Photoelectric
Operating Current
500 A max.
Humidity Range (Non-Condensing)
10-95% RH
Air Velocity Range
0-2000 FPM
Working Voltage
(MAPNET II and IDNet)
24-40 VDC
24V Working Voltage
(Sounder Power
Sounder Output
24V Standby Current
(Sounder)
24V Current
(Sounder Activated)
Remote LED Output
NO
Continued on next page
4098 TrueAlarm QuickConnect Smoke Sensors
Overview
Specifications
