5-2
This section describes the compatibility between FACPs, detectors, and detector bases.
Table 5-1. 4098 Detector and Detector Base Compatibility
Detectors
Compatible 2-
Wire Detector
Base
System
Max. Quantity
of Bases per
Initiating
Circuit
4098-9601 4098-9788 2120 ET/FADM 25
4098-9602 4098-9684 2120 FABT/VPBT 18
4098-9603 (LED base for 2120/4100+ ZAM 20
4098-9605 Heat Detectors 4001 18
4098-9612 Only) 4002 30
4098-9613
4020 30
4098-9614
4100ES/4100U/4100+/4120/UT 30
4098-9615
4004/4005 20
4006 30
4004/4005 High Current 30
4098-9683
(Relay base not used with
4004 and 4005 Low Current
systems)
1
(See Note 1)
Notes:
1. Relay operation cannot be guaranteed unless it is the only device on that zone.
2. Panel compatibility identification marker is model number of the module or panel.
3. Detector compatibility identification marker is model number found on detector label.
4. For detailed interconnection data, see wiring diagrams for specific panels.
5. For additional compatibility listings see 579-832 for 2-wire detector compatibility charts.
Continued on next page
Compatibility
Compatibility for
4098 Detectors and
Detector Bases
