Simplex 4098 Applications Manual

2-7
All heat detectors identified in the table below mount to a detector base (refer to the “4098 Bases”
section of this publication for more information). Use the information in Figure 2-1 when
mounting.
Table 2-3. Heat Detector Specifications
Product ID Description Application
Max. Spacing
Allowed (UL)
FM
4098-9612
Fixed-Temp. Only,
135 F (57 C)
Unusually violent
temp. fluctuations
and ceiling
temperatures not
exceeding
100 F (38 C)
70 X 70 ft
(21 X 21 m)
RTI = Quick
20 X 20 ft
(6.1 X 6.1 m)
4098-9613
Fixed-Temp. and
Rate-of-Rise,
135 F (57 C)
Normal temp.
fluctuations
and ceiling
temperatures not
exceeding 100 F
(38 C)
70 X 70 ft
(21 X 21 m)
RTI = Quick
20 X 20 ft
(6.1 X 6.1 m)
4098-9614
Fixed-Temp. Only,
200 F (93 C)
Unusually violent
temp. fluctuations
and ceiling
temperatures
exceeding 100 F
(38 C) but not
150 F (68 C)
70 X 70 ft
(21 X 21 m)
RTI = Quick
20 X 20 ft
(6.1 X 6.1 m)
4098-9615
Fixed-Temp. and
Rate-of-Rise,
200 F (93 C)
Normal temp.
fluctuations
and ceiling
temperatures
exceeding 100 F
(38 C) but not
150 F (68 C)
70 X 70 ft
(21 X 21 m)
RTI = Ultra Fast
50 X 50 ft
(15.2 X 15.2 m)
4098 Heat Detectors, Continued
Specifications
