The 4098-9788 base is designed to be used with 4098 Series smoke and heat detectors, as well as
the QuickConnect2 photo sensor. To use a 4-wire configuration, you must use the 4098-9682
relay base. Heat detectors require the 4098-9684 base when used with a remote LED. This
section only covers the information necessary to mount and wire these base configurations.
Before installing these bases, make a survey of the area to be covered in accordance with
information provided in NFPA 72. For additional information, refer to the NEMA Guide for
Proper Use of System Smoke Detectors.
CAUTION: Install the bases in this section in accordance with applicable NFPA
standards, local codes, and Authorities Having Jurisdiction (AHJs).
Failure to follow these instructions may result in failure of the detector
to initiate an alarm condition. The manufacturer is not responsible for
detectors that have been improperly installed, tested, or maintained.
