39
32
2
(2)Set the "Action".
Press the [CHANGE] button to set at
"1". And then press the [SET] button.
At that moment, the display changes
to the following figure.
The "Ext. Signal" and the "Built-in
Buzzer" are available only when
"Optional Board" is connected to the
time recorder.
(3)Set the "Hour".
In case of example, press the
[CHANGE] button to set at "9". And
then press the [SET] button.
At that moment, the flashing changes
from the "Hour" to the "Minute".
(4)Set the "Minute".
In case of example, press the
[CHANGE] button to set at "00". And
then press the [SET] button.
MO TU WE TH FR SASU
MO TU WE TH FR SASU
BUZZ EXT.
SIGNAL
*OFF *ON
MO TU WE TH FR SASU
Hour
SELECT CHANGE SET
TIME TABLE
PROGRAM
SELECT CHANGE SET
TIME TABLE
PROGRAM
MO TU WE TH FR SASU
BUZZ EXT.
SIGNAL
*OFF *ON
SELECT CHANGE SET
TIME TABLE
PROGRAM
BUZZ EXT.
SIGNAL
*OFF *ON
SELECT CHANGE SET
TIME TABLE
PROGRAM
BUZZ EXT.
SIGNAL
*OFF *ON
SELECT CHANGE SET
TIME TABLE
PROGRAM
1.
2.
3.
4.
Action
Special mark "*" ON
Special mark "*" OFF
Ext. Signal ON
Built-in Buzzer ON
31
Minute
Selected
Day of the week
Selected Action
ENGLISH
38
