Simplex EP40 User Manual

44
19. SETTING THE EXTERNAL TIME SIGNAL / BUILT-IN BUZZER
45
38
37
1
Press the [SELECT] button and position
the " " over the "EXT. SIGNAL /
BUILT-IN BUZZ." mark.
At that moment, the flashing digit
indicates the "Ext. Signal".
(The flashing means it can be changed.)
2
Change the "Ext. Signal".
In case of the example, press the
[CHANGE] button to set at "30". And
then press the [SET] button.
At that moment, the flashing changes
from the "Ext. Signal" to the "Built-in
Buzzer".
Change the "Built-in Buzzer".
In case of the example, press the
[CHANGE] button to set at "10". And
then press the [SET] button.
3
This function is to set the durations of External Time Signal and Built-in Buzzer. For the
number of seconds, 1 through 30 can be selected.
Note:For this feature to be functional, the optional board must be installed in the Time
Recorder.
Example: Change the External Time Signal to 30 seconds and the Built-in Buzzer to 10 seconds.
SELECT CHANGE SET
EXT. SIGNAL
BUILT-IN BUZZ.
EXT. SIGNAL
BUILT-IN BUZZ.
EXT. SIGNAL
BUILT-IN BUZZ.
SELECT CHANGE SET
SELECT CHANGE SET
SELECT CHANGE SET
EXT. SIGNAL
BUILT-IN BUZZ.
After you finish setting the external
time signal / bulit-in buzzer, press the
[SET] button once again.
4
Now the external time signal / built-in
buzzer setting has been completed.
Replace the cover and lock.
Important: If you do not complete Step
4, the Time Recorder will not print.
MO TU WE TH FR SASU
Ext.
Signal
Built-in
Buzzer
