Maintenance
20221586B 105
• HI value parameters for automatic steering at low speed with
a power boat and when running with a sailboat.
• LO value parameters for automatic steering at high speed and
when sailing into the wind or reaching with a sailboat.
Step through the menu items by pressing the STBD or PORT
buttons. Adjust the value by rotating the course knob.
Manual parameter adjust
Boat type Own boat
Displayed
parameter
Displacem.
& Sail
Planing
Automatic
tuning
Manual
Use course
knob to adjust
parameters
LOw
Rudder LO 0.35 0.20
Cont.Rudder LO 1.00 1.00
Autotrim LO 40 sec. 40 sec.
Rudder Lim LO 20° 20°
HIgh
Rudder HI 0.50 0.30
Cont.Rudder HI 1.40 1.40
Autotrim HI 40 sec. 40 sec.
Use PORT and
STBD buttons
to step through
parameters
Rudder Lim HI 20° 20°
Note ! The values in the table are factory set (default) and listed for
information only. After having performed the Automatic tuning,
the values may differ from those listed in the table. See also
“Automatic Tuning” previously in this chapter.
The two most important parameters that determine the
performance of the automatic steering are Rudder and Counter
Rudder.
