Technical specication | BSM-3 Installation Manual
Technical specication
Compliance and environmental
Compliance CE, C-TICK
Technical
standards
IEC 60945,
IEC 60529
Waterproof IPX5
Humidity Up to 95% at 35°C non-condensing
Storage
temperature
–30°C to +70°C
Operating
temperature
–15°C to +55°C
General
Connectors 6 Glands and 1 Ethernet
Weight 4.8 kg (10.6 lbs)
Dimensions
(WxHxD) mm/
in
340x100x289 mm
(13.38x3.94x11.37 inches)
Mounting 4 keyholed mounting tabs
Power requirements
Power
consumption
Range dependent – normally less than 10 W
Sonar specications
Power output 250 Watts RMS
2,000 Watts (peak to peak)
Frequencies Broadband Frequencies Transceiver High:
130-210 kHz; 85-145 kHz
Broadband Frequencies Transceiver Low:
40-60 kHz; 25-45 kHz
Narrowband Frequencies Transceiver High:
200 kHz; 83 kHz
Narrowband Frequencies Transceiver Low:
50 kHz; 38 kHz; 28 kHz
Transmitter and
receiver type
Dual Broadband tuned receivers
Dual tuned CHIRP transmitters
5
