| 21
Dimensional drawings | BSM-3 Installation Manual
Dimensional drawings
340 mm (13.38”)
320 mm (12.60”)
100 mm (3.94”)109 mm (4.29”)
250 mm (9.84”)
289 mm (11.38”)
