Chapter 8-2 CE34/44/54 Setup menu
To open the drawer below the keypad, press the eject key next to the
drawer. Place the cartridge in the tray with the terminals pointing
towards the unit, and push the drawer back in place - make sure it is
closed tight, so it remains watertight.
ENT
Press [ENT] to test the data on the C-MAP C-card
ī
If a C-card is defect, it must be removed before you can exit the display.
MENU
Exit the window
In addition to the larger boundaries of the world chart there will be
separate boundary lines for the individual charts stored on the same
cartridge. However, the boundary lines for the C-MAP chart areas
can be turned off, so they will not be visible on the chart - refer to
section 3.5 Chart setup.
Other chart areas can quickly be reached by means of the zoom keys:
+
Zoom out until desired area becomes visible
Move cursor to approximate area, and...
-
Zoom in
The chart will automatically start to move when cursor reaches the
edge of the screen. When cursor is switched off [CLR], the chart will
return to shipās position.
8.2 Echosounder setup
The Echosounder setup display mainly consist of general settings,
but also applies to a specific frequency where stated. The CEXX
features single and dual transceiver transmitting at 38 (44/54), 50
and 200 kHz.
MENU
Call up the menu bar, and...
6
open the SETUP menu, and...
ECHO
load Echosounder setup display
To Next Page
