CE34/44/54 Setup menu Chapter 8-3

CE34 example:

Echosounder setup:

Transducer:

SINGLE 200kHz

00.0 m

Keel depth below surface: 00.0 m

Display: DEPTH BELOW KEEL

Data on NMEA-out from: NONE

Alarm for fish: Strength: 065% OFF

Depth DS fish: min: 0005 m max: 0030 m

Depth DK alarm min.: 0005.0 m OFF

Depth DK alarm max.: 0030.0 m OFF

Water profile: SALT

Velocity of sound in water: 1470m/s

Time/distance scale: ON

Restart of AUTO pulse/power: 20 sec.

Echo sampling: BOTTOM

Demo mode: OFF

Exit Accept

ENT

CE44/54 example:

Echosounder setup:

Select transducers:

TYPE PORT

Transducer 1: NONE ECHO1

Transducer 2: NONE ECHO2

BEAM ANGLE DEPTH
