CE34/44/54 Chart menu and INFO windows Chapter 3-17
3.5 Chart setup
The settings are dedicated to the chart in the active window and does
not affect the second chart in dual chart mode.
ADJ
Load chart setup related to active chart
◄
GOTO
Presentation Dep
PLOT
►
Display mode FULL
Orientation NORTH UP
Rotation resolution 15°
Motion RELATIVE
Quick chart info ON
Cursor 5 min.time-limit ON
Auto chart select ON
Extended level range OFF
Show range WITH BACKGROUND
MENU
Exit Accept
ENT
The tabs indicate which groups are available in each display mode
e.g. the above example shows that in FULL display mode you have
access to the groups in black: General, Areas and User data. The
two groups in red i.e. Presentation and Depth are only adjustable
in CUSTOM display mode. See further on in this chapter for more
details.
+/-
Select display mode: FULL, CUSTOM, SIMPLE, FISHING, LOW,
GRID
PLOT
Go to the next group
GOTO
Step back to the previous group
Scroll up/down in the chart settings
∆
∆
General
To Next Page
