Chapter 2-2 CE34/44/54 Fundamentals & initial start-up
Long press on the [PAGE] key will start a
rotation of the three pages in intervals of
5 seconds (increase/decrease the time in
[MENU], [6], [1]). Press any key to stop
rotation.
2.1.1 Example of how to exchange a page in the PAGE system
The three pages in the PAGE system are collected from the CHART,
ECHO and PILOT menus in the sequence of which the function keys
appear on the keypad ie. the first page is from the CHART function,
the second page is from the ECHO function and the third page is
from the PILOT function. This sequence can not be changed, only
the choice of display collected from each function can be changed
e.g.:
PAGE
Press the [PAGE] key until the full screen Chart display appears
MENU
Call up the menu bar, and...
1,2
collect the Dual Chart display
- or you can toggle between the available displays in the CHART
function by pressing (long press) the [CHART] key repeatedly.
The same applies for the other two pages in the PAGE system ie.
press the [PAGE] key until a display from the ECHO or PILOT
function appears and then collect a new display from the appropriate
menu.
The display sequence under the function keys is the same as the
display sequence in the matching menu.
2.1.2 Example of how to select a new display in a custom screen
In custom screens with multiple window combinations, all dis-
plays, which are not main function displays, are exchangeable. It is
also possible to change the right half of the screen from half screen
window to two quarter windows and vice versa. Example:
MENU
Call up the menu bar, and...
