CE34/44/54 Setup menu Chapter 8-1
8. Setup menu
6
SETUP
CHART
C-MAP cartridges - see section 8.1
ECHO
Echosounder setup - see section 8.2
PILOT
Pilot/Position setup - see section 8.3
1
Speed alarm, units & language - see section 8.4
2
Interface setup - see section 8.5
3
Palette setup - see section 8.6
4
Factory settings - see section 8.7
5
QuickGuide - see section 8.8
8.1 C-MAP cartridges
On the unit’s front, below the keypad, are two watertight drawers
wherein you place the C-MAP cartridge/C-card you wish to load.
Do not attempt to insert or remove a cartridge unless the unit is
turned off, or chart reading is in stand-by - see below.
MENU
Call up the menu bar, and...
6
open the SETUP menu, and...
CHART
load the pop-up window for C-MAP cartridges (which also brings
the chart system in stand-by)
C-MAP cartridges
UPPER
Name: EAST DENMARK AND WEST SWEDEN
Code: EN-C161.4
Date: 14/09/2002
LOWER
Name:
Code:
Date:
MENU
Exit Test
ENT
To Next Page
