Simrad CE34 ChartSounder User Manual

Chapter 2-4 CE34/44/54 Fundamentals & initial start-up
TR ACK
Shortcut to starting/stopping the track function.
CHART
Shortcut to Chart function. Short press will toggle between differ-
ent data fields on chart. Long press will toggle between Chart in full
screen, Dual Chart, and two custom screens.
ECHO
Shortcut to Echosounder functions. Long press will toggle between
Echo display in full screen with A-scope, Dual Frequency (CE44/
54), and two custom screens.
PILOT
Shortcut to Pilot displays. With navigation mode inactive: single
press will toggle between Highway, Position, Dual Speed and Set &
Drift displays. With navigation mode active: short press will toggle
between Highway, Position, Dual Speed, ETA & AVN, Trim &
Highway, and Set & Drift displays. Long press will toggle between
Pilot full screen and two custom screens.
PAGE
Toggles between active pages under the three main function keys i.e.
[CHART], [ECHO] and [PILOT]. Long press starts automatic rota-
tion of these pages. Press any key to stop rotation.
ADJ
Gives access to setup displays related to active display.
A-B
Shortcut to the A-B function (with cursor active on chart display),
which provides bearing and distance from your current cursor posi-
tion (A) to an arbitrary point (B).
WIN
Toggles between active windows in split screen. The active window
will have a solid red frame. Only active windows are operable.
0-9
The alphanumeric keys inserts and selects data in data displays.
Keys 1-9 are also Quick-range keys, which each represent a fixed
chart range or echosounder range. Key 0 will center the cursor/ship
on the chart or activate auto range in sounder mode.
CLR
Turns cursor off in active display. Deletes data in enter or edit mode.
PWR
Power on - hold key depressed till you have a picture on the screen.
Calls up a window where you can adjust the brightness in the screen,
background light in keypad, and select Daylight displays, Night
display or custom made color palettes. Hold two seconds to turn the
power off.
