CR34/44/54 Radar menu Chapter 3-21
The tabs indicate which groups are available in each display mode e.g.
in the above example,
OVERLAY display mode, you have access to the
groups in black: General, Areas and User data. The two groups in red
i.e. Presentation and Depth are only adjustable in
CUSTOM display
mode. See further on in this chapter for more details.
+/-
Select display mode: OVERLAY, FULL, CUSTOM, SIMPLE,
FISHING, LOW
PLOT
Go to the next group
GOTO
Step back to the previous group
Scroll up/down in the chart settings
- functions in light grey are not accessible in selected display mode.
+/-
Toggle between available settings
ENT
Confirm changes, or...
MENU
Abandon Chart setup without making any changes
Display modes in the overlay chart setup
There are 6 different display modes to choose from: OVERLAY (default),
FULL, CUSTOM, SIMPLE, FISHING and LOW. When a group is shown in
red or a function is shown in light grey it is not available in the selected dis-
play mode. The default settings in the various display modes are:
Group: General - specification of chart display in general.
The available functions are according to display example on previous page for
all display modes and any change of the default settings will be applied in all
display modes.
Group: Presentation - specifies presentation of marine, land and chart topics
The default settings in this group are fixed in all display modes, except for
*Custom where it is possible by the user to turn a feature ON (shown on the
chart) or OFF (not shown on the chart), etc. - see next page.
