Simrad DD15 - Technical Specifications

Technical Specifications
20222303 / A 21
5 TECHNICAL SPECIFICATIONS
Dimensions:............................................................See Figure 5-1
Weight: ................................................................. 12 Kg (26.5 lb.)
Motor voltage: ......................................................................... 12V
Clutch voltage: ........................................................................ 12V
Average power consumption: ........................................... 2 Amps
Output torque: .................................................................150 Kgm
177 [6.9]
321 [12.5]
345 [13.5]
140 [5.5]164 [6.4]
10 [0.4]
77 [3]
Figure 5-1 DD15 Dimensional drawing
